Kyocera S10LSCLCR0612A Right-Hand, Positive Rake, Dynamic Bar Boring Bar with 5 Degree Lead Angle and 12.00mm Minimum Bore Dia.

Maximum structural thickness for higher toolholder rigidity and controlled chattering for stable machiningLarge chip pocket provides superior chip evacuationMaintains high cutting edge positional accuracy through the use of a special alloy, thereby achieving high precision machining0 (Axial), -12 (Radial) Rake Angle Dynamic Bar Boring BarGreat for Boring, Internal Facing ApplicationsProduct Details:Toolholder Style: S...SCLC-AHand of Holder: Right-HandRake: PositiveRake Angle (Degree): 0 (Axial), -12 (Radial)Series: Dynamic BarLead Angle (Degree): 5[DMIN] Minimum Bore Diameter (mm): 12.00[DCON] Shank Diameter (mm): 10.00[H] Shank Flat Width (mm): 9.00[LF] Functional Length (mm): 140.00[LH] Head Length (mm): 20.00[WF] Cutting Edge Distance (mm): 6.00[RE] Standard Corner Radius (mm): 0.40Maximum Overhang Length (L/D): ~4.0Coolant Through (Yes/No): NoInsert Holding Method: ScrewInsert Shape: 80 Degree Diamond[IC] Insert Inscribed Circle (mm): 6.35[S] Insert Thickness (mm): 2.38Multi-Use Tool (Yes/No): YesApplication: Boring, Internal FacingBar Type: SteelUnit (inch/mm): mmCompatible Insert Hand : Left-HandCompatible Inserts (Partial): CCGT215…, CCMT215…, CCET215…, CCGW215…, CCMW215…

• Maximum structural thickness for higher toolholder rigidity and controlled chattering for stable machining
• Large chip pocket provides superior chip evacuation
• Maintains high cutting edge positional accuracy through the use of a special alloy, thereby achieving high precision machining
• 0 (Axial), -12 (Radial) Rake Angle Dynamic Bar Boring Bar
• Great for Boring, Internal Facing Applications
